MAHLE 030 41 00 Piston
EAN: 4009026524879
91.43 EUR
Inc. VAT 21%
Ready for dispatch:
Monday, 14 April, 2025
| Fedex express: | Price from 5.00 € |
| DPD: | Price from 5.00 € |
| Fedex standart: | Price from 5.00 € |
Payments methods:
Technical Specifications
| Standard Size [STD]: | |
| Fitting Position: | to cylinder 3 |
| Fitting Position: | to cylinder 4 |
| Fitting Position: | for cylinder 3-4 |
| Cylinder Bore [mm]: | 79.51 |
| Length [mm]: | 71.8 |
| Compression Height [mm]: | 45.8 |
| Bolt length [mm]: | 66 |
| Bolt Ø [mm]: | 26 |
| Recess Depth 1 [mm]: | 17.65 |
| Recess Diameter [mm]: | 37.9 |
| Valve pocket depth 1 [mm]: | 1.1 |
| Machined: | with cut-out for oil jet |
| Surface: | Coated |
| Supplementary Article/Info 2: | with piston ring carrier |
| Supplementary Article/Info 2: | without cooling duct |
| Top land height [mm]: | 9.1 |
| Production Number: | 79 L 46 |
| Piston Clearance [mm]: | 0.07 |
| Component Number: | 1. R 1.75 Cr P |
| Component Number: | 2.M2.0 IFU Cr P |
| Component Number: | 3. DSF 3.0 Cr |
| Packaging height [cm]: | 12.8 |
| Net Weight [g]: | 780 |
| Packaging length [cm]: | 9.5 |
| Packaging width [cm]: | 9.5 |
OEN Number
| AUDI: | 028107065AB |
| AUDI: | 028107065AC |
| AUDI: | 028107065AK |
| AUDI: | 028107065AM |
| AUDI: | 028107065BD |
| AUDI: | 028107065CA |
| AUDI: | 028107065CB |
| AUDI: | 028107065J |
| AUDI: | 028107101AK |
| AUDI: | 038107065AB001 |
| AUDI: | 038107065AB003 |
| AUDI: | 038107065DD |
| AUDI: | 038107065J |
| AUDI: | 038107065L |
| VW: | 028 107 065 A B |
| VW: | 028 107 065 A C |
| VW: | 028 107 065 A K |
| VW: | 028 107 065 A M |
| VW: | 028 107 065 B D |
| VW: | 028 107 065 C A |
| VW: | 028 107 065 C B |
| VW: | 028 107 065 J |
| VW: | 028 107 101 A K |
| VW: | 038 107 065 AB001 |
| VW: | 038 107 065 AB003 |
| VW: | 038 107 065 D D |
| VW: | 038 107 065 J |
| VW: | 038 107 065 L |
| CUPRA: | 028107065AB |
| CUPRA: | 028107065AC |
| CUPRA: | 028107065AK |
| CUPRA: | 028107065AM |
| CUPRA: | 028107065BD |
| CUPRA: | 028107065CA |
| CUPRA: | 028107065CB |
| CUPRA: | 028107065J |
| CUPRA: | 028107101AK |
| CUPRA: | 038107065AB001 |
| CUPRA: | 038107065AB003 |
| CUPRA: | 038107065DD |
| CUPRA: | 038107065J |
| CUPRA: | 038107065L |
Similar Spare Parts
| KOLBENSCHMIDT: | 94428700 |
| NÜRAL: | 87-114900-95 |
