ATE 24.0109-0136.1 Brake Disc
EAN: 4006633078542
30.32 EUR
Inc. VAT 21%
Payments methods:
Technical Specifications
| Outer Diameter [mm]: | 280 |
| Brake Disc Thickness [mm]: | 9 |
| Minimum thickness [mm]: | 8 |
| Brake Disc Type: | solid |
| Number of Holes: | 3 |
| Machining: | High-carbon |
| Surface: | Coated |
| Height [mm]: | 38 |
| Centering Diameter [mm]: | 58 |
| Inner Diameter [mm]: | 153.5 |
| Bolt Hole Circle Ø [mm]: | 112 |
| Bore Ø [mm]: | 12.5 |
| Supplementary Article/Info 2: | with bolts/screws |
| MAPP code available: | |
| Test Mark: | E1 90R-02C0165/0468 |
Similar Spare Parts
| A.B.S.: | 17161 |
| ABE: | C3M050ABE |
| AIC: | 53658 |
| ALTE AUTOMOTIVE: | 128208FCAL |
| ASHIKA: | 60-0M-000 |
| ASHIKA: | 60-0M-000C |
| ATE: | 24.0110-0331.1 |
| BLUE PRINT: | ADU174308 |
| BOSCH: | 0 986 478 479 |
| BREMBO: | 08.8163.10 |
| BREMBO: | 08.8163.11 |
| CHAMPION: | 562155CH |
| CIFAM: | 800-538C |
| DELPHI: | BG3526 |
| DENCKERMANN: | B130412 |
| FEBI BILSTEIN: | 22345 |
| FERODO: | DDF1111 |
| FERODO: | DDF1111C |
| FTE: | 9072259 |
| FTE: | 9082182 |
| FTE: | BS5157 |
| FTE: | BS5157B |
| HELLA: | 8DD 355 106-601 |
| HELLA: | 8DD 355 127-411 |
| HELLA PAGID: | 8DD 355 106-601 |
| JAPANPARTS: | DI-M00 |
| JAPANPARTS: | DI-M00C |
| JAPANPARTS: | DIM00JM |
| JAPKO: | 60M00 |
| JAPKO: | 60M00C |
| JURID: | 562155JC |
| KRAFT AUTOMOTIVE: | 6048530 |
| LPR: | M2721PR |
| MAGNETI MARELLI: | 360406033800 |
| MAGNETI MARELLI: | 361302040131 |
| MASTER-SPORT GERMANY: | 24010901361-PCS-MS |
| MASTER-SPORT GERMANY: | 24010901361-PCS-MSP |
| MASTER-SPORT GERMANY: | 24010901361-SET-MS |
| MASTER-SPORT GERMANY: | 24010901361-SET-MSP |
| MAXGEAR: | 19-1203 |
| MAXGEAR: | 19-1203SPORT |
| METELLI: | 23-0538C |
| METZGER: | 6110040 |
| MEYLE: | 015 521 2077 |
| NK: | 203348 |
| NK: | 313348 |
| OPTIMAL: | BS-6320 |
| OPTIMAL: | BS-9260 |
| OPTIMAL: | BS-9260C |
| QUARO: | QD3457 |
| SKF: | VKBD 80381 S2 |
| STELLOX: | 6020-1313-SX |
| STELLOX: | 6020-1313K-SX |
| SWAG: | 99 92 2345 |
| TEXTAR: | 92097603 |
| TRUCKTEC AUTOMOTIVE: | 02.35.257 |
| TRW: | DF4135 |
| VAICO: | V30-40058 |
| VALEO: | 186859 |
| VALEO: | 673165 |
